Oceanography

Aquadopp

6000 m, Generation 2

High-performance full ocean depth, single-point current meter with titanium housing

  • Single-point current meter
  • Titanium housing for long-term deployments at full ocean depth
  • Ideal for deep water moorings

Overview

With all the robust and easy-to-use features and capabilities of the standard Aquadopp, the deepwater Aquadopp 6000 m current meter has been used and proven by oceanographers around the world for almost 20 years. Thanks to innovative data diagnostic features for challenging environments, it provides exceptionally high-quality 3D currents in a form factor that is easy to install in any type of mooring line configuration, or simply attached to a bottom or surface platform.

The 6000 m Aquadopp now offers 6% broadband measurements and “hibernation mode” between measurements, enabling precise data collection with lower power consumption. The upgraded deepwater Aquadopp design also offers increased internal battery storage, extending potential deployment duration.

See the details of the Generation 2 Aquadopp updates in the release notes here.
Download our guide to Aquadopp ADCPs here.
  • Currents

Highlights

  • Single-point current meter
  • Titanium housing for long-term deployments at full ocean depth
  • Ideal for deep water moorings
  • LED blinks when pinging for peace of mind during deployment

Usage

  • Studies of deep-water currents
  • Attached to mooring lines
  • Combined with riser monitoring systems
  • Near-bed current measurements from landers

Setup

Nortek deployment software allows users to customize their 600m Aquadopp deployment in a straightforward manner, providing guidance on deployment schemes, battery power and required internal memory.

Deployment

The 6000m Aquadopp is the ideal current meter for deep-water moorings. The instrument is capable of very long-term, unsupported deployments thanks to its low power consumption, internal data collection and ability to run entirely on internal battery power.

Data

Nortek postprocessing software and/or display software is available for review, visualization, and processing of data, after deployment or in real time.

Download PDF

Water velocity measurements

Cell size

0.75 m

Maximum number of cells

1

Blanking distance

0.1-5.0 m (user-selectable)

Velocity range (along beam)

User-selectable 1.0 to 5.0 m/s

Accuracy

±1% of measured value ±0.5 cm/s

Horizontal velocity precision (consult instrument SW)

Typ. 1 cm/s

Maximum sampling rate (output)

1 Hz

Echo intensity

Sampling

Same as velocity

Resolution

0.5 dB

Dynamic range

70 dB

Transducer acoustic frequency

2 MHz

Number of beams

3 (see GA drawing for angles)

Beam width

0.85° (1.7° total)

Sensors

Temperature:

Temp. range

-4 to +40 °C

Temp. accuracy/resolution

0.1 °C/0.01 °C

Temp. time response

<1 min

Compass:

Solid state magnetometer

Accuracy/resolution

<2° for tilt < 30° / 0.01°

Tilt:

Solid state accelerometer

Accuracy/resolution

0.2° for tilt < 30° / 0.01°

Maximum tilt

Full 3D

Up or Down

Automatic detect

Pressure:

Piezoresistive

Range

6000 m

Accuracy/precision

0.5% FS / 0.005% of full scale

Digital inputs

No. of channels

1

Digital input format

MicroCat CTD

Data recording

Capacity

16 GB

Real-time clock

Accuracy

±1 min/year

Backup in absence of power

4 weeks

Data communications

I/O

RS-422 (inquire for RS-232)

Communication baud rate

9600 Baud- 1.2 Mbaud (default 115200 Baud)

User control

Nortek Deployment Software or direct ASCII commands, with binary or ASCII data output

Software

Operating system

Cross platform

Functions

Deployment planning, instrument configuration, data retrieval and conversion. Online data display.

Power

DC input

9-24 VDC

Absolut maximum DC input

26 VDC

Maximum peak current

4.5 A

Power consumption

Consult Nortek Deployment Software

Sleep current

< 40 uA

Transmit power

Adjustable

Batteries

Internal battery capacity

1-3 x 50 Wh (Alkaline); 2-3 x 165 Wh (Lithium); 1-3 x 76 Wh (Li-ion)

Battery weight

430g per 50 Wh (Alkaline); 380g per 165 Wh (Lithium); 300g per 76 Wh (Li-ion)

Environmental

Operating temperature

-5 to +40 °C

Storage temperature

-20 to +60 °C

Shock and vibration

Shock: IEC 60068-2-27, Vibration: IEC 60068-2-64

EMC

EN IEC 61000-6-2:2019, EN IEC 61000-6-4:2019

Depth rating

6000m

Connectors

Bulkhead (Impulse)

MCBH-8-FS titanium

Cable

PMCIL-8-MP on 5m (default) polyurethane cable

Materials

Standard model

Titanium Gr. 5, POM, Naval Brass, epoxy

Dimensions (see drawings for details)

Maximum housing diameter

84 mm

Maximum length

623 mm

Weight

Weight in air (without batteries)

7600 g

Weight in water (without batteries)

4350 g

Arrangements

D2VC

Deep water, 2Mhz, Vertical orientation, Current meter
